Cámara IP Hikvision DS-2CD2T86G2-4I 8MP PRO IR80m 2.8mm H265+ POE SD WDR Acusense

• Camera
• Image Sensor - 1/1.8" Progressive Scan CMOS
• Min. Illumination - Color: 0.003 Lux @ (F1.6, AGC ON), 0 Lux with IR
• Shutter Speed - 1/3 s to 1/100,000 s
• Slow Shutter - Yes
• Wide Dynamic Range - 120 dB
• Day & Night - IR Cut Filter
• Angle Adjustment - Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360°

• Lens
• Lens Type - Fixed lens, 2.8/4/6 mm
• FOV - 2.8 mm, horizontal FOV: 110.7°, vertical FOV: 59.1°, diagonal FOV: 131° 4 mm, horizontal FOV: 87.1°, vertical FOV: 47.4°, diagonal FOV: 101.8° 6 mm, horizontal FOV: 50.8°, vertical FOV: 27.6°, diagonal FOV: 60°
• Aperture - F1.6
• Lens Mount - M16

• Illuminator
• IR Range - -2I: up to 50 m -4I: up to 80 m
• Wavelength - 850 nm

• Video
• Max. Resolution - 3840 × 2160
• Main Stream - 50Hz: 20fps (3840 × 2160, 3072 × 1728), 25fps (2688 × 1520,1920 × 1080, 1280 × 720) 60Hz: 20fps (3840 × 2160, 3072 × 1728), 30fps (2688 × 1520,1920 × 1080, 1280 × 720)
• Sub Stream - 50Hz: 25fps (640 × 480, 640 × 360, 320 × 240) 60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)
• Third Stream - 50Hz: 25fps (1280 × 720, 640 × 480, 640 × 360, 320 × 240) 60Hz: 30fps (1280 × 720, 640 × 480, 640 × 360, 320 × 240)
• Video Compression - Main stream: H.265+/H.264+/H.265/H.264 Sub-stream: H.265/H.264/MJPEG Third stream: H.265/H.264
• Video Bit Rate - 32 Kbps to 16 Mbps
• H.264 Type - Baseline Profile/Main Profile/High Profile
• H.265 Type - Main Profile
• Scalable Video Coding (SVC) - H.264 and H.265 encoding support
• Region of Interest (ROI) - 1 fixed region for main stream, sub-stream and third stream

• Network
• Simultaneous Live View - Up to 6 channels
• API - ONVIF (PROFILE S, PROFILE G), ISAPI, SDK
• Protocols - TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS
• User/Host - Up to 32 users, 3 levels: administrator, operator and user
• Security - Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for ONVIF, TLS1.2
• Network Storage - microSD/SDHC/SDXC card (256 GB), local storage and NAS (NFS,SMB/CIFS), ANR
• Client - iVMS-4200, Hik-Connect, Hik-Central
• Web Browser - Plug-in required live view: IE8+, Chrome 41.0-44, Firefox30.0-51, Safari8.0-11 Plug-in free live view: Chrome 57.0+, Firefox 52.0+

• Image
• Day/Night Switch - Day/Night/Auto/Schedule
• Image Enhancement - BLC, HLC, 3D DNR
• Image Settings - Saturation, brightness, contrast, sharpness, AGC and white balance adjustable by client software or web browser

• Interface
• On-board Storage - Built-in micro SD slot, up to 256 GB
• Hardware Reset - Reset via reset button on camera body, web browser and client software
• Communication Interface - 1 RJ45 10M/100M self-adaptive Ethernet port

• Event
• Basic Event - Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error), scene change detection

• Deep Learning Function
• Premier Protection - Line crossing detection, intrusion detection, region entrance detection, region exiting detection (Human&Vehicle classification)

• General
• Linkage Method - Upload to FTP/NAS/memory card, notify surveillance center, send email, alarm output, audible warning, trigger capture
• Web Client Language - 32 languages English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil)
• General Function - Anti-flicker, three streams, heartbeat, mirror, privacy masks, pixel counter
• Storage Conditions - -30 °C to 60 °C (-22 °F to 140 °F), humidity 95% or less (non-condensing)
• Startup and Operating Conditions - -30 °C to 60 °C (-22 °F to 140 °F), humidity 95% or less (non-condensing)
• Power Supply - 12 VDC ± 25%, two-core terminal block; reverse polarity protection; PoE (802.3at, class 4)
• Power Consumption and Current - -2I: 12 VDC, 0.63 A, max. 7.5 W; PoE (802.3af, 36 V to 57 V), 0.25 A to 0.16 A, max. 9 W -4I: 12 VDC, 0.88 A, max. 10.5 W; PoE (802.3af, 36 V to 57 V), 0.34 A to 0.21 A, max. 12 W
• Camera Dimension - Camera: Φ 105 × 290 mm (Φ 4.1" × 11.4") With package: 386 × 156 × 155 mm (15.2" × 6.1" × 6.1")
• Camera Weight - Camera: approx. 1270 g (2.8 lb.) With package: approx. 1510 g (3.3 lb.)

• Approval
• EMC - FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 6, 2016); KC (KN 32: 2015, KN 35: 2015)
• Safety - UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013); BIS (IS 13252(Part 1):2010+A1:2013+A2:2015); LOA (IEC/EN 60950-1)
• Environment - CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
• Protection - Ingress protection: IP66 (IEC 60529-2013), IK10(IEC 62262:2002)
