Transceptor pasivo de video HD de 16 canales por par trenzado Utepo UTP116P-HD


74.38€
(90.00€
con IVA)
+2ud. 67.77€
  Transceptor pasivo de video HD de 16 canales por par trenzado Utepo UTP116P-HD

Descripción


Transceptor pasivo de video HD de 16 canales por par trenzado Utepo UTP116P-HD


The 4ch passive HD (non-amplified) video UTP transceiver allows transmission of real-time and high-performance color or monochrome (B/W) CCTV video or HDCVI/AHD/HDTVI HD video over UTP cable,perfect for multi-point surveillance.

Features:
1.Passive,no need of power supply;
2.HDCVI HDTVI AHD CVBS 4 in 1 Compatible design; Real-time transmission, no delay;
3.Recommendation transmission distance as below:
1) HDCVI1080p: 100m ; HDCVI 720P: 370m( passive to passive);
2)HDTVI 720P/1080p: 200m ( passive to passive);
3) AHD-L/M 720p/960P: 330m; AHD-H 1080P: 330m(passive to passive);
4)Analog video: 500m ( passive to passive);
4.RJ-45 or green terminal block to be chosen to connect UTP cable;
5.Protection: Strong surge protection, ESD and lighting protection;
6.Structure: delicate design, support MIT structure, easy operation.

Imágenes



Características técnicas

Items

Description

Function

Channels

16 Channel

Transmission Distance

Please refer to table 1

Video
properties

Video Connector

BNC-F

UTP Cable Connector 8 pin green terminal block,RJ-45
Compatible With PAL,NTSC, SECAM video
HDCVI/AHD/HDTVI HD video
Signal Transmission Band 0-70MHz
Interference Rejection >60db
Video Connector Protection 2KV(common mode) Per:IEC61000-4-5
UTP Cable Connector
Protection
2KV(different mode) Per:IEC61000-4-5

Protection

ESD

Contact Discharge:6000V

Air Discharge:8000V
Per:IEC61000-4-2

Physical
Properties

Dimension (LWH)

430*100*44.5mm(1U design)

Shell

Iron Metal

Color

Black

N.W.

1.181kg

Environmental

Operating Temperature

0~50°C

Storage Temperature

-40°C ~85°C

Humidity (non-condensing)

0~95%
